Gd- 1884 Digital Hydrometers API Gravity Liquid Petroleum Densitometer ASTM D1298

Product Description

Liquid and Crude Oil Densimeter Density Tester with Portable Cooler

Introduction:

This instrument is designed and made as per standards GB/T 1884-2000 Crude petroleum and liquid petroleum products - Laboratory

determination of density - Hydrometer method and ASTM D1298 Standard Test Method for Density, Relative Density(Specific Gravity),or API Gravity of Crude

Petroleum and Liquid Petroleum Products by Hydrometer Method. It is used to determine the density of crude petroleum and liquid petroleum.

Features:

I. Main technical features

1. This instrument is a kind of all-in-one machine. The control box adopts humanized design. The control switch adopts light-touch mode.

It's structure is simple and compact. Easy to operate.

2. It adopts intelligent LCD temperature controller. The control rate is fast and overstrike is small. The temperature control can reach ±0.2ºC.

3. It equips a hard glass vessel and electric stirrer. The temperature in vessel is uniform. Easy to observe the sample.

4. It equips a model ZL-1 portable cooler. It can do refrigeration for the liquid in the vessel according to test requirements.

II. Main technical specifications

Constant temperature bath

1. Power supply:	AC(220±10%)V, 50Hz
2. Dimension of bath:	300mm×340mm
3. Capacity of cylinder:	500ml
4. Heating power:	700W, 1000W
5. Temperature controller:	(1) Range: Ambient to 100ºC (2) Accuracy: ±0.2ºC (3) Sensor: Pt100
6. Thermometer:	Mercury-in-glass thermometer. Scale division is 0.2ºC.
7. Dimension:	560mm×380mm×580mm

Gd-1884 Digital Hydrometers API Gravity Liquid Petroleum Densitometer ASTM D1298

Portable cooler

1.Power supply: AC(220±10%)V, 50Hz

2.Cooling Power: 180W

3.Refrigeration: Totally enclosed type compressor

4.Refrigerant: R134a,environment friendly

5.Ambient temperature: (5~35)ºC

6.Relative humidity: ≤85%

7.Dimension: 450mm×400mm×300mm

Exhibition

We have developed sales channels in many countries such as the UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, the USA, Mexico, Kenya, Nigeria, South Africa, and other countries worldwide. And we have

gained a strong advantage and high reputation in the international market.

After several years' development, our products have become highly intelligent and wide coverage.
And our company has become one of the leading manufacturers of petroleum testing instrument and electrical testing

instrument.

Gd-1884 Digital Hydrometers API Gravity Liquid Petroleum Densitometer ASTM D1298

Packing

Goods are packed in veneer case, which is firm and safe for overseas shipment.
