Tape Initial Tack Tester

Product Description

Tape Initial Tack Tester

1. Temperature Controller: PID control
2. Safety Device: Overheating or power overload protection

Introduction:
Constant temperature tape testing equipment simulates the adhesive tape in hot temperature environment, and the auto-timer records the holding time of adhesive tape with specific load to confirm the effective time of adhension. The timer shall retain the tseting time automatically to assess the durability of adhesive tape in hot temperature enviroment when the tape falling down from the plate.

Constant temperature tape testing equipment Specifications:

Model	HD-C525
Test Fixture	10 groups (Timing independently)
Load	1 Kg or designated
Timer	10 sets, 9999.9 minutes
Temperature Controller	Normal Temp.~200 °c, PID control
Accuracy	0.1 °c
Heating System	Hot Air Circulation
Safety Device	Overheating or electric power overload protection automatically
Material	Inside: Stainless Steel; Outside: Advanced steel plate (paint handling)
Inside Dimension (L×W×H)	45×50×45 cm
Outside Dimension (L×W×H)	97×65×110 cm
Weight	105 Kg
Power	1phase, AC220V, 15A
Design Criteria	CNS-11887/11888; PSTC-7; GB/T 4851

The main technical parameters:

Test Fixture	10 groups (Timing independently)
Load	1 Kg or designated
Timer	10 sets, 9999.9 minutes
Temperature Controller Normal Temp.	~200 ° C, PID control
Accuracy	0.1 ° C
Heating System	Hot air Circulation
Safety Device	Overheating or electric power overload protection automatically
Material Inside	Stainless Steel;
Outside	Advanced steel plate (paint handling)
Inside Dimension	(L× W× H) 45× 50× 45 cm
Outside Dimension	(L× W× H) 97× 65× 110 cm
Weight	105 Kg
Power	AC220V, 15A
Design Criteria	CNS-11887/11888; PSTC-7; GB/T 4851

The introduction of Haida:
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.
Tape Initial Tack Tester

Packaging & Shipping:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.

After-service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
