Product Description
General information:
Low voltage short circuit impedance measurement is the routine test item of transformer, SXDZ-II Low Voltage Short Circuit Impedance Analyzer is used for 35kV and above main transformers. It's both suitable for on site and laboratory test.
Features:
√ Small size, light weight.
√ Voltage and current sampling synchronously and signal digital signal processing technology, measurement data is accurate.
√ Adapts single phase measurement. When the transformer connection is selection, every phase short circuit can be calculated well automatically after three times measurements.
√ Low current measurement can be calculated to rated current automatically, suitable for on-site test.
√ Voltage, current, power can be measured synchronously. The frequency of apply power supply is also can be measured.
√ Built in printer. No power failure memory for test data long storage.
√ LCD screen, friendly interface, easy to operate. The data can be read clearly even in direct sunlight.
Specifications:
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
Low voltage short circuit impedance measurement is the routine test item of transformer, SXDZ-II Low Voltage Short Circuit Impedance Analyzer is used for 35kV and above main transformers. It's both suitable for on site and laboratory test.
Features:
√ Small size, light weight.
√ Voltage and current sampling synchronously and signal digital signal processing technology, measurement data is accurate.
√ Adapts single phase measurement. When the transformer connection is selection, every phase short circuit can be calculated well automatically after three times measurements.
√ Low current measurement can be calculated to rated current automatically, suitable for on-site test.
√ Voltage, current, power can be measured synchronously. The frequency of apply power supply is also can be measured.
√ Built in printer. No power failure memory for test data long storage.
√ LCD screen, friendly interface, easy to operate. The data can be read clearly even in direct sunlight.
Specifications:
Measurement accuracy: | Voltage, current 0.2% |
| Power: | COSφ>0.1: 0.5 %; COSφ≤0.1:1.0% |
| Impedance: | COSφ>0.1: 0.5 %; COSφ≤0.1:1.0 % |
| Measurement range of voltage: | AC 10V~600V |
| Measurement range of current: | AC 0.5A~10A |
| Working temperature: | -10ºC--50ºC |
| Humidity: | 0-80% |
| Power supply: | AC220V±10,50Hz±1Hz |
| Dimension: | 360*220*150mm |
| Weight: | abou t 5kg |
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
