Uni T Ut595 Earth Ground Line Loop Impedance Electrical Installation Tester
Uni-T Earth Resistance RCD multifunction Loop Testers UT595I.DescriptionUT593/UT595 is a multifunction digital safety testing instrument, designed with combin-ation of large-scale integrated analog & digital circuits and micro-processor chip. It mai-nly measures RCD, line/loop impedance, continu......
Send Inquiry
Product Description
Uni-T Earth Resistance RCD multifunction Loop Testers UT595
I.Description
UT593/UT595 is a multifunction digital safety testing instrument, designed with combin-ation of large-scale integrated analog & digital circuits and micro-processor chip. It mai-nly measures RCD, line/loop impedance, continuity, insulation resistance, DC and AC voltage, phase sequence, featuring versatile functionality, higher accuracy, stable perfor-mance and ease of use. The instrument is widely used to measure RCD, insulation and earth connections for various equipments, and an ideal tool for testing, inspection and maintenance badly needed for various electric devices and RCDs.
II.Parameter:
III. Detailed Photos
IV. Company Information
HuaZheng Electric Manufacturing (Baoding) Co., Ltd is the supplier of the State Grid in China. It means we are the supplier of the Chinese Government. And our products spread throughout the whole China.
What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malaysia, Vietnam and so on.
Our main products are Digital Multimeter, Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.
V. Our Services
1. 24 hours hot line.
2. We supply OEM service.
3. Our engineers available to service machinery overseas.
4. We can produce the products as your request.
5. To produce high quality products, services to the public.
6. To act quickly, seize the opportunity, continuous innovation, the pursuit of excellence.
VI. FAQ
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Baoding city, Hebei province, China.
You can go to Baoding by train directly.
All our clients, from home or abroad, are warmly welcome to visit us!
3. Q: How can I get some samples?
A: We are honored to offer you samples.
4. Q: How does your factory do regarding quality control?
A:Quality is priority.we always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained BV, CE,ISO, SGS authentication.
5. Q: May I send deposit by Paypal?
A: yes, for the small amount, we accept paypal.
6. Q: May I know your payment term?
A: Mostly, we work with: FOB / CNF / CIF or EX-WORK.
100% by T/T before delivery. Small amount by T/T or Western Union or Paypal are acceptable.
7. Q: May I know your delivery term?
A: Depending on your quantity, for goods we have in stock, Delivery takes 2 days to comply with your
request.
For Regular order, delivery takes between 20-30 days.
VII. Customer Visit
VIII.Exhibition
I.Description
UT593/UT595 is a multifunction digital safety testing instrument, designed with combin-ation of large-scale integrated analog & digital circuits and micro-processor chip. It mai-nly measures RCD, line/loop impedance, continuity, insulation resistance, DC and AC voltage, phase sequence, featuring versatile functionality, higher accuracy, stable perfor-mance and ease of use. The instrument is widely used to measure RCD, insulation and earth connections for various equipments, and an ideal tool for testing, inspection and maintenance badly needed for various electric devices and RCDs.
II.Parameter:
| Specifications | Range | Best Accuracy | |
| Model | UT595 | ||
| Insulation Resistance (Ω) | Test Voltages | 250V/500V/1000V | ±10% |
| 250V | 0.05MΩ~250MΩ | ±(5%+5) | |
| 500V | 0.05MΩ~500MΩ | ||
| 1000V | 0.05MΩ~1000MΩ | ||
| Short-Circuit Current | <2mA | √ | |
| Low Resistance Continuity Test(Ω) | Range | 0.00Ω~199Ω | ±(2%+5) |
| Test Current | 0.00~2Ω: >200mA | √ | |
| Line Impedance (Ω) | Range | 0.01Ω~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~440V(45Hz~65Hz) | √ | |
| Test Current | 20A | √ | |
| PFC Range | 0KA~26KA | √ | |
| Loop Impedance (Ω) | Range | 0.01Ω~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ | |
| Test Current | 20A | √ | |
| PFC Range | 0KA~26KA | √ | |
| Loop Impedance Without Tripping(Ω) | Range | 1.00Ω~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ | |
| Test Current | 15mA | √ | |
| PFC Range | 0KA~26KA | √ | |
| RCD | Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ |
| Test Current | 10mA/30mA/100mA/300mA/500mA | ±10% | |
| Trip Time | ×1/2 *I n Range:0ms~2000ms | ±(5%+5) | |
| ×1 *I n Range:0ms~300ms | ±(5%+5) | ||
| ×1 *I n Range:0ms~500ms(Selective Countdown) | ±(5%+5) | ||
| ×2 *I n Range:0ms~300ms | ±(5%+5) | ||
| ×2 *I n Range:0ms~500ms(Selective Countdown) | ±(5%+5) | ||
| ×5 *I n Range:0ms~40ms | ±(5%+5) | ||
| Phase Sequence Test | Operational Voltage(Freq.) | 100V~440V(45Hz~65Hz) | √ |
| Indication | Order:L1→ L2→ L3 Positive change;L1→ L3→ L2 To reverse | √ | |
| RCD Measurement RAMP Slope | Test Current Range | 10mA/30mA/100mA/300mA/500mA | ±10% |
| AC Voltage (V) | Range | 0V~440V | ±(5%+2) |
| Frequency Response | 45Hz~60Hz | √ | |
| Resolution | 1V | √ | |
| Features | |||
| Display Count | 9999 | ||
| Auto Power Off | √ | ||
| Low Battery Indication | √ | ||
| Data Logging | √ | ||
| LCD Backlight | √ | ||
| Auto Half-wave Test | √ | ||
| RCD Countdown Measurement | 30 Seconds | √ | |
| RCD Half-wave Test | √ | ||
| Phase Switch(RCD) | 0°and 180° | √ | |
| General Characteristic | |||
| Power | 1.5V Batteries(LR6) X 6 | ||
| LCD Size | 125mm X 37mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 1000g | ||
| Product Size | 210mm X 175mm X90 mm | ||
| Standard Accessories | Batteries, Test Lead (1 x Green, 1x Black, 1 x Red), Specialized Test Lead, Remote Control Test Lead | ||
| Standard Individual Packing | Gift Box, Tool Box, User Manual | ||
| Standard Quantity Per Carton | 4 PCs | ||
| Standard Carton Measurement | 510mm X 330mm X 300mm (0.051CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 15Kg | ||
